Sublue WhiteShark MixPro Sinks in Fresh Water: Diagnosis

⚠️ SAFETY WARNING / FIRE HAZARD. This device contains lithium batteries. Improper puncturing or bending during disassembly can cause explosions or flames. The intervention requires precision and the assistance of a specialized technician is recommended. ReeFix provides this diagnosis EXCLUSIVELY for educational and informational purposes.

IF the Sublue WhiteShark MixPro sinks slowly or is heavier than usual, even with the float installed:

• Quick checks:
  1. Visual inspection of the float: Look for cracks, fissures, or signs of impact on the outer surface of the Sublue WhiteShark MixPro Float. Even a micro-fissure can compromise the seal.
  2. Separate float test: Remove the float and immerse it in a tub of water. If air bubbles emerge, there is an infiltration. Shake it: if water is felt inside, it is damaged.
  3. Float weight: If you have a precision scale, weigh the dry float. A weight significantly higher than specifications indicates trapped water.
• Key signs: The device sinks not rapidly, but steadily. The float itself seems "heavy" or makes a liquid noise when shaken.
• Most probable cause: Water infiltration into the float (Floater). This happens in 50% of cases with this symptom. Water, being denser than air, reduces its hydrostatic thrust.
• Costs and decision: The cost of a new Sublue WhiteShark MixPro Float is usually between €30 and €50. Replacement is simple and can be done independently.
• Common mistake: Not rinsing and drying the float thoroughly after use, which can mask small cracks or accelerate degradation.

IF the float is intact but humidity or oxidation is found in the battery compartment:

• Quick checks:
  1. O-ring inspection: Carefully remove the Sublue WhiteShark MixPro Battery and inspect the main O-ring for cuts, crushing, sand, or loss of elasticity.
  2. Battery compartment check: Use a strong light to look for traces of moisture, salt deposits, or oxidation on the gold-plated contacts.
• Key signs: Water droplets or condensation inside the battery compartment after use. The battery contact pins might show slight discoloration or patina.
• Most probable cause: Wear, deformation, or lack of lubrication of the battery compartment O-rings. This is responsible for 30% of cases. O-rings are the first line of defense against water.
• Costs and decision: A Sublue WhiteShark MixPro O-Ring Gasket Kit costs about €15-€25, plus a tube of underwater silicone grease for €5-€10. O-ring replacement is an operation that can be attempted independently with care, but requires precision to avoid future flooding. If the battery shows signs of swelling or extensive oxidation, it must be replaced (high cost).
• Prevention tips: Regularly lubricate O-rings with specific underwater silicone grease after every 3-5 dives, or if the device remains unused for long periods.

IF the first two cases are negative, but abnormal noises from the motors or low power are noticed:

• Quick checks:
  1. Dry motor test: Briefly turn on the device (out of water, with caution) and listen for unusual noises from the motors (rubbing, imbalance).
  2. Duct inspection: Check the propeller grilles and internal ducts for debris, sand, or algae that could obstruct water flow or retain weight.
• Key signs: Power drop or irregular operation of one or both motors. The device might tend to unbalance sideways.
• Probable cause: Water infiltration into the brushless motor housings (15%) or accumulation of debris in the ducts (5%). Water in the motors can cause short circuits or corrosion, while debris increases weight and alters hydrodynamics.
• Costs and decision: Infiltration into the motors is a serious and costly problem to repair, often requiring the replacement of the entire motor unit or complex internal components. Labor for this repair is high (€40-€80) and the cost of spare parts can be significant. If the problem is only debris, cleaning is simple and incurs no costs. If the infiltration has damaged the Sublue WhiteShark MixPro Battery, costs increase further.

If you notice that the Sublue WhiteShark MixPro battery does not charge or if, upon power-on, the five LED indicators continuously flash red, the internal circuit may have entered a safety lock due to moisture. In these cases, attempting to force charging is risky, and often the only safe solution is the complete replacement of the battery pack.

• Output for technician: "The device sinks in fresh water, float and battery compartment checked and intact. I suspect infiltration into the motor housings or obstruction of the ducts. I request motor seal test and internal inspection."

THEN:

If initial checks on the float and O-rings reveal no problems, it is crucial not to underestimate the integrity of the motors. A precision screwdriver set can help with inspections, but for the motors, a technician is recommended. Safety notes: Never attempt to open the sealed motor compartments without proper experience; you could irreparably compromise the watertight seal. Real micro-case: "Often, after an apparently harmless impact, micro-cracks form in the float that only become apparent after several dives, when water slowly penetrates."

CONCLUSION:

1. If the float is damaged (50% probability): Purchase a new Sublue WhiteShark MixPro Float (€30-€50) and replace it yourself.
2. If the O-rings are worn or not lubricated (30% probability): Purchase a Sublue WhiteShark MixPro O-Ring Gasket Kit and underwater silicone grease (€20-€35 total) and proceed with replacement and lubrication, or consult a technician for a safer intervention (€40-€80 labor).
3. If you suspect motor problems or the Sublue WhiteShark MixPro Battery is damaged (15-20% probability): Immediately contact a specialized technician. Repair costs could be high (over €100-€150), making device replacement an option to consider if the damage is extensive.
